> >SUA5000rmi5u Core only

SUA5000rmi5u Core only

SUA5000rmi5u Core only View larger

SUA5000rmi5u-core-30d

Used

Tested working UPS - 30 days RTB warranty

does not include cells, front plastic, control panel, rackmount ears or top.

We test the units as normal before taking the cells out again and packing.

More details

This product is no longer in stock

£ 260.00 tax incl.

Output power capacity 4.0 KWatts / 5.0 kVA

Nominal Output Voltage 230V
Output Voltage Note Configurable for 220 : 230 or 240 nominal output voltage
Efficiency at Full Load 96.0 % Output Voltage Distortion Less than 5% at full load
Output Frequency (sync to mains) 47 - 53 Hz for 50 Hz nominal
Other Output Voltages 220, 240
Topology Line Interactive
Waveform type Sine wave

Nominal Input Voltage 230V
Input frequency 50/60 Hz +/- 3 Hz (auto sensing)Input Connections Hard Wire 3-wire
Input voltage range for main operations 160 - 286V
Input voltage adjustable range for mains operation 151 - 302V
Efficiency at Full Load 96.0 %

2x RBC55 cells (new)

Operating Temperature 0 - 40 °C
Audible noise at 1 meter from surface of unit 53.0dBA
Online thermal dissipation 430.0BTU/hr

Maximum Height 222mm , 22.2CM
Maximum Width 483mm , 48.3CM
Maximum Depth 660mm , 66.0CM
Rack Height 5U (or can be used as a tower)
Net Weight 97.73KG

  • Topology Line Interactive

No customer reviews for the moment.

Write a review

SUA5000rmi5u Core only

SUA5000rmi5u Core only

Tested working UPS - 30 days RTB warranty

does not include cells, front plastic, control panel, rackmount ears or top.

We test the units as normal before taking the cells out again and packing.
